عمق الحقل

A macro photograph with very shallow depth of field.

Shallow depth of field can yield dramatic results and greatly emphasize the subject.

عمق الميدان أو الحقل Depth of field واختصارها DOF وهي المسافة بين الجسم القريب والخلفية الأبعد والخارجة عن نطاق التركيز في الصورة وكمثال : عندما تصور شخص ويكون واضح المعالم في الصورة ولكن الخلفي أو المنظر الذي خلفة يكون غير واضح وخارج نطاق التركيز. ويمكن التحكم بهذا الشيء بواسطة فتحة العدسة APERTURE فإذا زادت الفتحة قل عمق الميدان والعكس عند تصوير المناظر الطبيعية مثلا.

A 35 mm lens set to f/11. The depth-of-field scale (top) indicates that a subject which is anywhere between 1 and 2 meters in front of the camera will be rendered acceptably sharp. If the aperture were set to f/22 instead, everything from 0.7 meters to infinity would appear to be in focus.

المساحة ضمن عمق الحقل تبدو حادة الملامح، بينما المساحات أمام وخلف عمق الحقل تبدو ضبابية.

Effect of aperture on blur and DOF. The points in focus (2) project points onto the image plane (5), but points at different distances (1 and 3) project blurred images, or circles of confusion. Decreasing the aperture size (4) reduces the size of the blur spots for points not in the focused plane, so that the blurring is imperceptible, and all points are within the DOF.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

 تعريف

Detail from the lens shown above. The point half-way between the 1 m and 2 m marks represents approximately 1.3 m.

هو عبارة عن مؤشر يبيّن نسبة المساحة التي ستبقى واضحة وضمن التركيز البؤري في المشهد المراد تصويره. والعمق الحقلي الكبير يعني مسافة متزايدة بين خلفية الصورة ذات التركيز البؤري الجيد وأمامية الصورة، مع تركيز بؤري جيد لكل شيء يقع بينهما. أما العمق الحقلي الضيّق فإنه يركز بؤرته على مجال صغير، اعتماداً على بعد العنصر المركزي عن الكاميرا. وعلى سبيل المثال، إذا كان موضوع التصوير هو شخص يقف بمفرده في حديقة، فإن استخدام عمق حقلي ضيق سيؤدي إلى أن معظم الحديقة ستبدو غير واضحة في الصورة، وسيبقى التركيز البؤري مركزاً على الشخص فقط. أما عند استخدام عمق حقلي كبير، فإننا سنحافظ على بقاء معظم الحديقة ضمن التركيز البؤري.

 معرض الصور

• DOF with various apertures
•

  f/22

•

  f/8

•

  f/4

•

  f/2.8

At f/32, the background competes for the viewer’s attention.

At f/5.6, the flowers are isolated from the background.

At f/2.8, the cat is isolated from the background.

The integrated circuit package, which is in focus in this macro shot, is 2.5 mm higher than the circuit board it is mounted on. In macro photography even small distances can blur an object out of focus. At f/32 every object is within the DOF, whereas the closer one gets to f/5, the fewer the objects that are sharp. The images were taken with a 105 mm f/2.8 macro lens. At f/5 the small dust particles at the bottom right corner set examples for the circle of confusion phenomenon.

Series of images demonstrating a 6 image focus bracket of A Tachinid fly. First two images illustrate typical DOF of a single image at f/10 while the third image is the composite of 6 images.

DOF for symmetrical lens.

Defocus blur for background object at B.
