Imaging lens Diastar of an Askania 35mm movie projector (focal length: 400 mm)
Christie AW3 platter, BIG SKY Industries console, and Century SA projector.nonrewind in Royal - Malmö, Sweden.
مصدر إضاءة.
عدسات عاكسة ومكثفة.
Douser.
بوابة الفيلم وإطار أمامي.
مصراع.
عدسات التصوير ولوحة الفتحة.
شاشة الرؤية.
Mechanical sequence when image is shown twice and then advanced. Outer sprockets rotate continuously while the frame advance sprockets are controlled by the mechanism shown - a Geneva drive.
A photo of a 35 mm film print featuring all four audio formats (or "quad track")- from left to right: SDDS (blue area to the left of the sprocket holes), Dolby Digital (grey area between the sprocket holes labelled with the Dolby "Double-D" logo in the middle), analog optical sound (the two white lines to the right of the sprocket holes), and the DTStime code (the dashed line to the far right.)
Simulated wide screen image with 1.96 to 1 ratio as it would be seen in a camera viewfinder or on a theater screenSimulated anamorphed image with 1.33 to 1 ratio (4:3) as it would appear on a frame of film
